Overview |
|
Description | Roll up high speed door. |
Applications | Industrial. |
Fitting | Internal face fit. |
Components |
|
Curtain | Polyester fabric coated with coloured PVC. Insulated and panelled versions available on request. One row of vision panels with rounded corners as standard, more available if required. |
Guides | Self supporting galvanised steel with brushes. Stainless steel AISI 304 or 316 available on request. |
Roller | Galvanised steel. |
Measurements |
|
Curtain Weight | 900g/m² (1300g/m² with insulation) |
Frame Thickness | 2mm |
Max Width | 6000mm |
Max Area | 30m² |
Operating Temperature | 0ºC to 70ºC |
Opening Speed | 1.2m/s |
Wind Load | Class 2 EN 12424. Class 3 available. |
Finish |
|
Curtain | Wide range of coloured PVC options to choose from. Silk screen and digital printing available on request. |
Operation |
|
Electric | Three phase, self braking motor and push button controls as standard. Remote control, radar and induction loop cards available. |
Rapid Roll High Speed Door
The roll up high speed door has been tested in working conditions to over 1.5 million cycles. It is therefore suitable for intensive and continuous use applications, in a wide range of industries, including iron and steel, engineering, textile, chemical and food processing. Minimal head and side room are required, and vision can be incorporated as standard. The three phase motor provides rapid opening of up to 1.2m/s, with appropriate safety systems incorporated.
Speak to the Roché team for advice on which security shutter is most suitable for your requirements. We can also arrange a free survey from one of our experienced engineers.
